Datasheet of 12V 100Ah
LifePO4 Batttery Pack |
Model No. |
CT-12V 100Ah |
Normial Voltage |
12.8V |
Norminal Capacity |
100Ah |
Max Chage Voltage |
14.4V |
Min Discharge Voltage |
8.8V |
Max Charge Current |
100A |
Max Discharge Current |
100A |
Charge Temperature |
0~45℃ |
Discharge Temperature |
-20~45℃ |
Terminal |
M8 |
Max Dimension |
330×173×216mm |
Casing and Color |
ABS Case(LCD DP) |
Life Cycle |
2000Cycles |
Weight About |
12Kg |
Water Proof |
IP54 |
Strage Temperature |
0~45℃ |
|
|
|
Datasheet of 12V 200Ah
LifePO4 Batttery Pack |
Model No. |
CT-12V 200Ah |
Normial Voltage |
12.8V |
Norminal Capacity |
100Ah |
Max Chage Voltage |
14.4V |
Min Discharge Voltage |
8V |
Max Charge Current |
200A |
Max Discharge Current |
200A |
Charge Temperature |
0~45℃ |
Discharge Temperature |
-20~45℃ |
Terminal |
M8 |
Max Dimension |
490×171×240mm |
Casing and Color |
ABS Case(LCD DP) |
Life Cycle |
2000Cycles |
Weight About |
22Kg |
Water Proof |
IP54 |
Strage Temperature |
0~45℃ |
|
|
|
Datasheet of 12V 400Ah
LifePO4 Batttery Pack |
Model No. |
CT-12V 400Ah |
Normial Voltage |
12.8V |
Norminal Capacity |
400Ah |
Max Chage Voltage |
14.4V |
Min Discharge Voltage |
8.8V |
Max Charge Current |
250A |
Max Discharge Current |
250A |
Charge Temperature |
0~45℃ |
Discharge Temperature |
-20~45℃ |
Terminal |
M8 |
Max Dimension |
560×550×220mm |
Casing and Color |
SteelCase(LCD DP) |
Life Cycle |
2000Cycles |
Weight About |
46Kg |
Water Proof |
IP54 |
Strage Temperature |
0~45℃ |
|
